24V 36V 48V 200Ah 600Ah Forklift Traction Car Automotive Lead Acid Batteries
Model: 6PZB600
Voltage: 36V
Capacity: 600Ah
N.W.: 710KG
Brand: NOVACELL
Max discharge current: 120A
Battery type: lead acid batteries
Size: T965*W345*L775mm
Advantages
- Cycle life: 2000+ cycles
- Quality: Grade A
- Price: Cheap
- Design life: 6 years
- Warranty: 2 years
- Working temp.: -20~50°C
- Environment Friendly: Yes
- Size: customizable
- Certificate: BIS KC CB PSE UL IEC62133 UN38.3
Application
- Electric Traction
- Electric Forklift
- Electric Motorcycle
- Solar storage
- Energy storage
- Electric Car
- Automotive
- Ebike
Specification
| Electrical Characteristics | Nominal Voltage | 36V |
| Nominal Capacity | 600Ah | |
| Energy | 21600Wh | |
| Battery type | Lead acid | |
| Cycle Life | 2000+ cycles | |
| Months Self Discharge | ≤3% per month at 25℃ | |
| Standard Charge | Charge Voltage | 36~43.2V |
| Charge Mode(CC-CV-FC) | At 0℃~25℃, CC-CV-FC | |
| Standard Charge Current | 60A(0.1C) | |
| Max.Charge Current | 300A(0.5C) | |
| Standard Discharge | Standard discharge Current | 60A(0.1C) |
| Max. Discharge Current | 600A(1C) | |
| Discharge Cut-off Voltage | 31.5V | |
| Environmental | Charge Temperature | 0℃~45℃ |
| Discharging | -10℃~65℃ | |
| Storage temperature | -20℃~50℃ | |
| Storage Humidity | ≤85% RH | |
| Mechanical | Battery | 18 cells + cables |
| Housing | SPCC | |
| Battery Dimension(L*W*H*) | T965*W345*L775mm | |
| PCM | N/A | |
| N.W.: | Approx. 710Kg |
More Details
We offer a range of lead acid batteries, including forklift, automotive, and traction batteries. Please specify the type and capacity you require.
OEM&ODM SERVICE
Welcome to consult more customized process
- 1.Customizable Housing
- 2.Customizable Dimensions
- 3.Customizable Functions
- 4.Customizable Parameters
1.Customizable Housing
2.Customizable Dimensions
3.Customizable Functions
4.Customizable Parameters
